M8-LED

Bi-Directional Photocell Safety Light — 200 hr Runtime, 2 mile visibility, IP64 Reflective Ring

Color Blue
Amber
Amber
 Blue
Blue
 Clear
Clear
 Green
Green
 Red
Red

Color:

Amber
Blue
Clear
Green
Red

The M8-LED is a bi-directional photocell safety light whose eight LEDs make it Railhead's brightest mid-size unit at 2 miles of visibility for 200 hours, backed by a reflective outer ring that returns vehicle headlights even after the cell dies, and confirmed by a built-in LED indicator that shows during daylight that the light is on and the photocell is armed, sealed to IP66. Available in Blue (M8-LED) · Amber (M8-LED A) · Clear (M8-LED C) · Green (M8-LED G) · Red (M8-LED RS)

Best use case: Best for hazards approached from two directions, such as tracks, roadways, aisles, barricades, loading areas, and construction zones, using a bi-directional profile with steady or double-flash operation.

Additional Information

Features


  • • Reflective outer ring keeps the unit visible in headlights even with a dead battery
  • • Brightest mid-size light in the Railhead line — 8 LEDs, visible up to 2 mi
  • • Built-in indicator confirms the light is on and the photocell is armed during daylight
  • • 200 hr of runtime on (2) D cells
  • • Flashing and steady modes
  • • Bi-directional output

Material


  • Lens: Polycarbonate
  • Body: High Impact ABS
Specifications

Specifications


    • Light Source: 8 LEDs
    • Modes: Steady on / Double flash
    • Run Time: Up to 200 hr
    • Visibility: Up to 2 mi
    • Ingress Protection: IP64 (dust-tight, water-resistant)
    • Color: Amber / Blue / Clear / Green / Red
    • Dimensions (W × H): 5.0 in × 8.5 in
    • Weight: 1.5 lb (without batteries)
    • Battery: (2) D cell alkaline (not included)
