RH-VTAG VEHICLE TAG
ULTRA WIDEBAND TECHNOLOGY BASED VEHICLE TAG
FOR DETECTING MOVING PEDESTRIANS AND VEHICLES
• Detects other vehicles and pedestrians
• Activates Zone Tag Warning Strobes
• Simple installation and detachment using magnetic pads and a lever
• Detecting functions are unaffected by wind, falling rain or snow, fog, humidity, air temperature, or light
• IP65 enclosure withstands harsh environments
- Max. Detectable Distance: 98.5 ft
- Weight: 1 lb
- Power: DC 12V / 24V
- Operating Voltage: DC 9~32V
- Power Consumption: Below 4W
- Operating Temperature: -22F~185
- Ingress Protection Rating: IP65
RH-AIND AUDIO INDICATOR
INDICATOR FOR MAKING LIGHT/SOUND ALARM WHEN
VEHICLE TAG DETECTS PEDESTRIANS INTO WARNING AREAS
• Connects to Vehicle Tag
• Gives vehicle operator audio signals “Watch Out” and “Danger”
• Intelligent proximity alert system
• Indicator operates in warehouse, factory, port and construction/mining site as an alert device
• IP65 enclosure withstands harsh environments
• Light flash when activated
- Weight: 0.45 lb
- Power DC: 12V / 24V
- Operating Voltage: DC 9~32V
- Operating Temperature: -22F~185F
- Ingress Protection Rating: IP65
RH-PTAG PEDESTRIAN TAG
ULTRA WIDEBAND TECHNOLOGY BASED
PEDESTRIAN TAG FOR DETECTING MOVING VEHICLES
• Activates when in the proximity of vehicle tag
• USB rechargeable
• Simple installation and detachment using a helmet or a clipper holder
• Can select vibration, audio, or combination mode
- Max. Detectable Distance: 98.5 ft
- Weight: 0.121 lb
- Power: 950mAh 3.7V Li Polymer
- Charge Method: Micro USB Type B (5V/1A)
- Operating Temperature: -22F~185F
- Usable Time: Typical 30 hr (In condition of operating 10 times vibration)
RH-ZTAG ZONE TAG WARNING STROBE
ULTRA WIDEBAND TECHNOLOGY BASED TAG DETECTING
APPROACHING PEDESTRIANS OR VEHICLES
• Ultra wideband based proximity alert warning system
• Simple installation and detachment using magnetic pad or bracket
• Displays visible warning system
• Emits audio warning
• Can be used with audio amplifier and speaker option
- Max. Detectable Distance: 98.5 ft
- Weight: 1.06 lb
- Power: DC 12V / 24V
- Operating Voltage: DC 9~32V
- Power Consumption: Below 4W
- Operating Temperature: -22F~185F
- Ingress Protection Rating: IP65
RH-ZTAG P PASSIVE LIGHT
• Activates when connected to Zone Tag Strobe
• Can connect multiple units for area alerts
• Ultra wideband based proximity alert warning system
• Simple installation and detachment using magnetic pad or bracket
- Max. Detectable Distance: 98.5 ft
- Weight: 1 lb
- Power: DC 12V / 24V
- Operating Voltage: DC 9~32V
- Power Consumption: Below 4W
- Operating Temperature: -22F~185F
- Ingress Protection Rating: IP65
RH-PSPEAK ZONE TAG SPEAKER
• Used with Zone Tag, Strobe, and AMP
- Size: 4.8” × 5” × 4.8”
- Weight: 5.18lb
- Mounting Method: Fixed with screw
- Operating Temperature: -31 ~158F
- Speaker Output: 20W
- Impedance: 08ohm
- Sound Level / Distance: 96.2dB / 0.1m
RH-PAMP ZONE TAG AMP
• Used with Zone Tag, Strobe, and Speaker
RH-12VA 12V CIGAR JACK ADAPTER
RH-EXCABLE EXTENSION CABLE
RH-HCABLE HARNESS CABLE
RH-OWA OPEN WIRE ADAPTER
• Power Adapter for Vehicles Tag
RH-PAWSACADAPTER UNIVERSAL AC ADAPTER
• Power Adapter for Zone Tag Strobe
